eSpresso CC 575 EQ – Grey/Black – MY24
Highlights:
- Shimano Steps EP6 85Nm motor
- Internally mounted 750 Wh battery
- Shimano CUES 10-speed drivetrain
- Suspension fork and seat post
- Rugged 650b wheels Grippy high-volume tyres with reflective strip
- Mudguards, kickstand, rack, lock and lights
Low step-through fully equipped eBike. Slightly more rugged than an eSpresso City due to wider tyres. Powered by a Shimano Steps EP6 85Nm motor with large capacity 750Wh battery. 10 speed.
25% Deposit (Non-refundable): €975.00
Remaining 75% Balance: €2,925.00
The eSpresso CC is the rugged sibling of the regular eSpresso, with wider and grippier high-volume tyres on 650b wheels. Whilst it’s happy in the urban jungle thanks to standard-fit mudguards, lights, lock, rack and kickstand, it’s also capable of taking trips along forest trails and gravel tracks for fun. All eSpresso CC models are equipped with a refined, powerful Shimano STEPS pedal-assist motor. Smooth, comfortable progress is assured by suspension forks and powerful hydraulic disc brakes allowing effortless, controlled braking. All electric bikes have an approved rider and equipment weight of up to 150 kg, meaning there’s plenty of capacity for you and your luggage.
Specification
| Specification | Details |
|---|---|
| Frame | CC Lite III Hydroformed 6066 triple butted aluminium. Tapered head tube. 135 x 9mm axle standard. Cables routed internally via Smart Entry to hold them neatly and silent. Max. tyre size 27.5″ x 2.25″ |
| Motor | Shimano Steps EP6; 85Nm |
| Battery | Simplo Trend Power Internal Battery Gen 2; 750Wh |
| Battery Capacity | 750Wh |
| eBike Display | Shimano SC-EN500 |
| Charger | Trend Power Simplo EU Charger; 4A |
| Fork | Suntour NVX30 DS; Coil; 80mm travel; Max. tyre size 27.5″ x 2.4″ |
| Gears | 10 |
| Shifters | Shimano CUES U6000 |
| Rear Derailleur | Shimano Cues U6000; GS |
| Bottom Bracket | Part of Shimano Steps motor |
| Chain | Shimano LG500 |
| Chainset | Samox NWP203; 38 tooth chainset with Merida Expert TK; 165mm length crank all sizes with Sunnywheel SW-CG-173A chainguard |
| Cassette | Shimano LG300; 11-48 teeth; 10 Speed |
| Brake Lever | Shimano MT200 |
| Front Brake | Shimano MT200 2 piston hydraulic disc brake caliper with Shimano RT10 180mm rotor |
| Rear Brake | Shimano MT200 2 piston hydraulic disc brake caliper with Shimano RTEM300 180mm rotor |
| Grip | Merida Expert TK |
| Handlebar | Merida Expert; aluminium; 660mm wide; 15mm rise |
| Stem | Merida Expert CT; aluminium; 31.8mm diameter; adjustable; length: 90mm all sizes |
| Head Set | Merida-8254 |
| Pedal | VP Components – VPE-891 |
| Saddle | Merida Expert TK II; V-mount |
| Seat Post | JD-SP79; 30.9mm diameter; 15mm lay back; 40mm suspension travel |
| Wheel Size | 27.5″ |
| Rims | Merida Comp TK; 20mm inner rim width; aluminium |
| Spokes | Black stainless |
| Front Hub | Shimano QC300; 100 x 9mm; 32 spokes; Centerlock |
| Rear Hub | Shimano QC300; 135 x 9mm; 36 spokes; Centerlock |
| Front Tyre | Maxxis Crossmark II; 27.5″ x 2.25″; wire bead with reflective strip |
| Rear Tyre | Maxxis Crossmark II; 27.5″ x 2.25″; wire bead with reflective strip |
| Colour | Grey/Black |
| Season | 2024 |
| Front Light | Hermans H-Black MR4 E, LED front light – 120 Lumens |
| Rear Light | Spanninga Commuter Glow XE integrated rear light |
| Other | Complete with: Mudguards, kickstand, Abus frame lock and Merida MIK HD Carrier with Spring clip, elastic strap & Spanninga rear light. |
| Size | XSmall, Small, Medium, Large |
|---|
